Full Color Flexible HD LED Display Stage Led Screen For Wedding , Rental Business

Large Image : Full Color Flexible HD LED Display Stage Led Screen For Wedding , Rental Business Get Best Price

Product Details:

Place of Origin:	Shenzhen, China
Brand Name:	Newstar-LED
Certification:	CE, RoHS, UL, FCC, ISO
Model Number:	WS-10

Payment & Shipping Terms:

Minimum Order Quantity:	1 pc/ 1 sqm.
Price:	US $1,000-3,000 /sqm.
Packaging Details:	Flight case /Fumigation-Free wooden case
Delivery Time:	8-25days after received the payment
Payment Terms:	T/T
Supply Ability:	2000 Square Meter/Month

Contact Now

Detailed Product Description

High Light:

High Definition LED display

high resolution led screen

Full Color Flexible HD LED Display Stage Led Screen For Wedding , Rental Business

Quick Detail:

1. Special cabinet design, cooling fast

2. Wonderful product especially for stage use.

3. Available models:P7.81,P10.417, P12.5, P15.625.

4. Package with flight case, easy to move.

5. Ingress protection : IP31

6. Brightness: ≥5500 nit

P10.417 Indoor Lightweight colorful LED Display,Full Color For Wedding,Exhibition.

Description:

1. Slim Design

One cabinet size is 500 x 500 x 95mm

2. Fast lock design help to fast Assembly

No tools needed, can be installed with 1 person.

3. Angle Adjustment

Panel connection angle can be adjusted by -15 degree to +15 degree. This allows arc shape available.

Applications:

Live broadcast: Gym, Stadium, Concert, Sport match, Competition, Gov publication etc.

Rental business: Entertainment, Wedding, Party etc.

Specifications:

1. Indoor LED Display Technical Parameter

Brightness	≥5500 nit
Color temperature	6500/9000 K
Viewing angle-H	140 (+70/-70) deg.
Viewing angle-V	140 (+70/-70) deg.
Cabinet weight	8 kg
Cabinet size (W×H×D)	500×500×95 mm
Cabinet area	0.5 sqm.
Cabinet material	Aluminum
Ingress protection	IP31
Operating temperature	–40~+60 degree
Operating humidity	10%~ 90%
Pixel configuration	1R1G1B
Pixel pitch	10.417 mm
Module size	500x83.3 mm
Pixel matrix per module	48 x 8 dots
Pixel matrix per cabinet	48 x 48 dots
Pixels per cabinet	4,608 dots
Pixels per sq.m.	9,216 dots
Minimum viewing distance	10 m
Gray scale	256 level
Brightness control	5,500 nit
Refresh frequency	>2,000 Hz
Driving mode	1/4 scan constant current driving
Input voltage (AC)	100 ~ 240 V
Input power frequency	50 or 60 Hz
Power consumption per sq.m. (max/avg)	800/300 W
Blind spot rate	<1/10,000
Lifetime at 50% brightness	100,000 hours
Red wavelength (Typical)	623 nm
Green wavelength (Typical)	523 nm
Blue wavelength (Typical)	475 nm
Signal input format (with video processor)	AV, S-Video, VGA, DVI, YPbPr, HDMI, SDI
Operating system	Windows (2000/XP/Vista)
Control distance	CAT5 cable <100 m Single fiber <10 km

2. LED Curtain Cabinet

Dimensions(w x h x d)(mm)	500x500x95	Cabinet area	0.5 sqm.
Physical Resolution (w x h)	48 x 48	Physical Pixels (total)	4,608
Weight/Panel (kgs)	8	Material	Aluminum
Average Power/sqm (watts)	300	Max Power/sqm(watts)	800

3. Methods for Quality Assurance

a. Aging

1. 100% fully test

2. Condition: 72 hours with 256 grey level

b.Vibration Testing

Condition: 3-5 mins up and down in 5mm range

4. Factory Equipment

Wave Soldering Conveyor, PC Console, Wave Soldering Machine,
Automatic Glue- pouring Machine, Solder Paste Printing Machine,
Reflow Soldering Machine, Automatic Solder Paste Printing Machine,
Withstand Voltage Tester, Ground Resistance Tester,
Medium-speed Automatic SMT Machine, Super Mute Terminal Machine,
Automatic Wire Stripping Machine, Automatic Optical Inspection (AOI) Equipement.

5. Package

Flight case and Fumigation-Free wooden case

6. Control System Connection

7. Competitive Advantage:

1. 2 years’ warranty with free repair service

2. 24/7 Hours online remote support

3. Solution and PCB design

4. Free factory training

5. Onsite installation instruction and regular inspection
