Module packing group

cutting PCB board, using screw, combine mask and PCB with suite together to make a complete.Put on the masks and align the four corners, then press it lightly with hands. (Please noticed the direction of the masks).Press the module which put on the masks with the Pneumatic Fixture.QC inspects the evenness and the stickness of the masks after the pressure process.Fixture Pressing, test the module

wire processing group

All cables and wire produce by our factory. So we can control the accessories quality assurance and delivery date.

wire processing group

All cables and wire produce by our factory. So we can control the accessories quality assurance and delivery date.

Industrial park

Shenzhen Newstar Optoelectronics Co.,Ltd [ Location: 3rd.Building, Hengchangrong(Hi-Tech) Technology Park, Shilongzai, Shiyan Town,Shenzhen, China ]-National High Tech Enterprise Professional LED Screen Manufactuer

Industrial park

Shenzhen Newstar Optoelectronics Co.,Ltd [ Location: 3rd.Building, Hengchangrong(Hi-Tech) Technology Park, Shilongzai, Shiyan Town,Shenzhen, China ]-National High Tech Enterprise Professional LED Screen Manufactuer

Printing solder paste machine

Printing solder paste and checking,Check the PCB board after the printing, see if it has any soldering problem, such as the connected soldering, insufficient soldering, overflow soldering, displacement, etc.

Printing solder paste machine

Printing solder paste and checking.Printing solder paste and checking,Check the PCB board after the printing, see if it has any soldering problem, such as the connected soldering, insufficient soldering, overflow soldering, displacement, etc.

Printing solder paste machine

Printing solder paste and checking,Check the PCB board after the printing, see if it has any soldering problem, such as the connected soldering, insufficient soldering, overflow soldering, displacement, etc.

Lamp beads and IC driver collection

module material collection.1.Make sure the material load in the SMT Machine are same with the BOM.2.First, the QA need to inspect the direction and the placement of the components, make sure everything is ok, then start to produce.

Reflow soldering machine

reflow soldering after chip mounted.SMT engineer must make sure the temperature profile setting compliance with the requirements before go through the reflow soldering.

Assemble group

Assemble a cabinets with all of the appropriate artifacts. including module,PCB,cable,power supply,receiver card,lock, cabinets frame.

Assemble group

Assemble a cabinets with all of the appropriate artifacts. including module,PCB,cable,power supply,receiver card,lock, cabinets frame.

Module test room

Module need to display for 72 hours before fixed on the cabiets

Reflow soldering machine

mounter machine. Working fo chip and IC, capacitors, resistors. and other accreeories. which on module

Fxied screen packing

Permanent fixed screen will be packing on a wooden case.

Rental event screen packing

Rental event screen will be packing in filght case with wheel, it is convience for the rental video wall.
