Commercial Square P12 Outdoor Advertising LED Display Panel With High Brightness
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Tube Chip Color: | Full Color | LED Type: | 3mm Oval Lamp |
|---|---|---|---|
| Pixel Configuration: | 1R1G1B | Pixel Pitch: | 12mm |
| Product Name: | Full Color Outdoor Advertising Led Display/advertising Led Display | Use: | Outdoor |
| High Light: | led billboard advertising,digital billboard advertising |
||
Commercial Square P12 Outdoor Advertising LED Display Panel With High Brightness
Quick Detail:
1. High brightness: >6000cd/㎡,
2. Dynamic 1/4 duty Constant Current,
3. Refresh Frequency ≥240HZ, Frame Frequency ≥60HZ,
4. Best after sale service.24/7 hours online remote service
5. IP65 Ruggedness, all-weather qualified
6. Front service available, easy maintenance
2R1G1B P12 Outdoor Advertising LED Display Panel for Shopping Center , 6944 dots/m2
Description:
1. Special Structure design for water-proof, dust-proof, moisture-proof, and anti-static electric
2. Outstanding consistency in color and brightness, no mosaic effects.
3. High viewing angle: 110°(Horizontal )/45°(Vertical )
4. High Contrast. The Contrast is above 2000:1, so the viewer can have a wonderful visual
Applications:
Commercial advertising: Square, Road side, High way, Airport, Wharf, Hotel, Restaurant etc
Specifications:
1. Outdoor LED Display Technical Parameter
|
Model No. |
NS-OR-DD-P12 |
|
Pixel Pitch |
12mm |
|
Module Size |
192 mm ×192mm |
|
Module Resolution(Pixel) |
16 dots×16dots |
|
Pixel Density |
6944 dots/m2 |
|
LED Type |
3mm Oval Lamp |
|
Pixel Configuration |
2R1G1B |
|
Wavelength (R.G.B) |
R:625±2nm G:525±2nm B:470±2nm |
|
Drive Mode |
Dynamic 1/4 Duty Constant Current |
|
Cabinet Size |
1152×768×150mm |
|
Cabinet Resolution |
96dots×64dots |
|
Brightness |
≥6000 cd/m2 |
|
Contrast |
≥2000:1 |
|
Viewing Angle |
110°(Horizontal )/45°(Vertical ) |
|
Best Viewing Distance |
10~300 m |
|
Grey Scale |
10bits/1024levels |
|
Color Capability |
16777216 |
|
Color Temperature |
5000-9300K |
|
Maximum Power Consumption |
1000 W/m2 |
|
Average Power Consumption |
350W/m2 |
|
Working Voltage |
AC220V/110V s±15% 50-60 HZ |
|
Frame Frequency |
≥60HZ |
|
Refresh Frequency |
≥240HZ |
|
Brightness Correction |
Pixel, Module, Cabinet Correction |
|
Operating Temperature |
Static:-40°C ~ +85°C Working:-20°C ~ +60°C |
|
Operating Humidity |
10-90% RH |
|
LED Lifespan |
100,000 hours |
|
MTBF |
≥50000 hours |
|
Computer Operation System |
Win 98/ Win XP/ Win 2000 |
|
Video Signal Input |
RF,S-Video, RGB,RGBHV,YUV,YC,VGA, DVI, HDMI, SDI,HD-SDI ,Composite |
|
Video Signal Output |
RF, S-Video, GB, RGBHV, YUV, YC etc. |
|
Graphics Card |
DVI Graphics Card |
|
Control Distance |
UTP CAT5E:100m Multi-mode Fiber:500m Single-mode Fiber:10km |
|
Control System |
LINSN OR DB-STAR |
|
Software |
LED studio 10.0 |
|
Waterproof Level |
IP65(front side), IP54 (back side) |
|
Installation |
Wall mount, hung and stand structure |
|
Out of Control Rate |
0.01 % |
2. Outdoor LED Display Module
|
Module Size (W*H) |
192mm*192mm |
Pixel Configuration |
1R1G1B |
|
Pixel Pitch |
12mm |
Resolution (W*H) |
16 dots*16 dots |
|
Pixel Density |
6944dots/㎡ |
LED Type |
3mm Oval Lamp |
3. Outdoor LED Display Cabinet
|
Cabinet Size (W*H) |
1152mm*768mm |
Module Qty |
24 pcs |
|
Cabinet Resolution (W*H) |
96 dots*64 dots |
Cabinet Pixel |
6144 |
|
Weight |
40 kg/ Cabinet |
Area |
0.6144㎡ |
|
Average Power Consumption |
350w/㎡ |
Max Consumption |
1000W/m2 |
4. Methods for Quality Assurance
a. Aging
b. Vibration Testing
5. Factory Equipment
Wave Soldering Conveyor, PC Console, Wave Soldering Machine,
Automatic Glue- pouring Machine, Solder Paste Printing Machine,
Reflow Soldering Machine, Automatic Solder Paste Printing Machine,
Withstand Voltage Tester, Ground Resistance Tester,
Medium-speed Automatic SMT Machine, Super Mute Terminal Machine,
Automatic Wire Stripping Machine, Automatic Optical Inspection (AOI) Equipement.
6. Package
Flight case and Fumigation-Free wooden case
7. Control System Connection
8. Competitive Advantage:
1. Front/Rear access Available
2. Reasonable Price, Superior Service.
3. Long Life Span > 100,000 hours
4. Free maintenance service
5. High Quality and High performance
