SMD3528 P6 Indoor Video Flexible LED Display With High Brightness 1800cd/㎡
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Pixel Configuration: | 1R1G1B | Protection Ratings: | IP31 |
|---|---|---|---|
| Use: | Indoor | ||
| High Light: | flexible led signs,flexible led screen |
||
SMD3528 P6 Indoor Video Flexible LED Display With High Brightness 1800cd/㎡
Quick Detail:
1. ≤1mm surface level up, smooth video
2. Long lifespan up to 100,000 hours
3. IP31 Ruggedness, all-weather qualified
4. High brightness: >2000cd/㎡
5. Support any format of video, RF, S-Video, RGB, RGBHV, YUV, YC, COMPOSITION
6. Perfect quality and stability, 24/7 running
Description:
1. Safety. Using the low voltage DC so that no matter the elderly and children can safely operate without
potential safety hazard.
2. Softness. Using PCB as the substrate and can apply to various advertising model requirements.
3. Long lifespan. The normal operating time is 100000 hours. If worked all the day long, it would work
for at least 10 years.
4. Energy conservation and environmental protection. Using the environmental materials and
low power (0.04W-0.08W) so that cannot result in waste and pollution.
5. Easily installation. Using attaching clamp, wire casing, iron wire, iron net and can install on all kinds
of undertake surface. It can also be installed by the double-sided adhesive because of the light weight.
6. Pure color. Using the high bright SMT and the color is pure, downy and no glare
Applications:
Commercial advertising, mobile media, night club, entertainment events, business establishments, such as
banks, stock exchange centers, bus station, schools, telecommunications, customs, stadiums, studio,
shopping malls, railways, airports, harbors, etc;
Specifications:
1. Indoor LED Display Technical Parameter
|
Model No. |
NS-IR-DS-P6 |
|
Pixel Pitch |
6mm |
|
Module Size |
192*96mm |
|
Module Resolution(pixels) |
32*16 |
|
Panel Size |
960mm×768mm |
|
Panel Resolution(pixels) |
160×128 |
|
Pixel Configuration(RGB) |
1R1G1B |
|
Pixel Density(pixels/㎡) |
27,777 |
|
Brightness(cd/㎡) |
1800 |
|
Best Viewing Distance(m) |
6-100 |
|
Max.Power Consumption(W/㎡) |
1350 |
|
Waterproof Level |
IP31 |
|
Wavelength |
R 620-625 G 520-525 B 470-475 |
|
LED SPEC |
3528 |
|
Viewing Angle |
140°(H)/140°(V) |
|
Operating Temperature |
–20~60°C |
|
Video Frame Rate(Hz) |
≥60HZ |
|
Display Refresh Rate(Hz) |
≥300HZ |
|
Grey Level(colors) |
16.7million |
|
MTBF |
≥50000 hours |
|
Lifespan |
≥100000Hours |
|
Working Voltage |
220V±15% OR 110V±15% |
|
Drive Mode |
Constant 1/8 |
|
Graphics Card |
DVI Graphics card |
|
Video Signal |
RF, S-Video, RGB, RGBHV, YUV, YC, etc. |
|
Control System |
LINSN |
|
Software |
LED studio 10.0 |
|
Installation |
Wall mount, hung and stand structure |
2. Indoor LED Display Module
|
Dimensions (w x h) |
192mmx96mm |
Resolution (w x h) |
32 x 16 |
|
Pixel pitch |
6mm |
Pixel Density |
27,777/㎡ |
|
Pixel Configration |
1R1G1B 3 IN 1 |
LED Type |
SMD 3528 |
3. Indoor LED Display Cabinet
|
Dimensions(w x h x d)(mm) |
960 x768 x135mm |
Module Quantity |
40 |
|
Physical Resolution (w x h) |
160 x 128 |
Physical Pixels (total) |
20,480 |
|
Average Power/sqm (watts) |
1000w/panel |
Material |
Aluminum |
4. Methods for Quality Assurance
a. Aging
1. 100% fully test
2. Condition: 72 hours with 256 grey level
b. Vibration Testing
Condition: 3-5 mins up and down in 5mm range
5. Factory Equipment
Wave Soldering Conveyor, PC Console, Wave Soldering Machine,
Automatic Glue- pouring Machine, Solder Paste Printing Machine,
Reflow Soldering Machine, Automatic Solder Paste Printing Machine,
Withstand Voltage Tester, Ground Resistance Tester,
Medium-speed Automatic SMT Machine, Super Mute Terminal Machine,
Automatic Wire Stripping Machine, Automatic Optical Inspection (AOI) Equipement.
Automatic Glue- pouring Machine, Solder Paste Printing Machine,
Reflow Soldering Machine, Automatic Solder Paste Printing Machine,
Withstand Voltage Tester, Ground Resistance Tester,
Medium-speed Automatic SMT Machine, Super Mute Terminal Machine,
Automatic Wire Stripping Machine, Automatic Optical Inspection (AOI) Equipement.
6. Package
Flight case and Fumigation-Free wooden case
7. Control System Connection
8. Competitive Advantage:
1. 2 years’ warranty with free repair service
2. 24/7 Hours online Remote Support
3. Solution and PCB design
4. Free factory training
5. Onsite installation instruction and regular inspection
