Full Color Indoor Advertising LED Display

large.img.alt
small.img.alt small.img.alt small.img.alt

Large Image :  Full Color Indoor Advertising LED Display Get Best Price

Product Details:
Place of Origin: Shenzhen, China
Brand Name: Newstar-LED
Certification: CE, RoHS, UL, FCC, ISO
Model Number: NS-IR-DS-P6
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc/ 1 sqm.
Price: US $1,000-2,000 /sqm.
Packaging Details: Flight case /Fumigation-Free wooden case
Delivery Time: 8-25days after received the payment
Payment Terms: T/T
Supply Ability: 2000 Square Meter/Month
Detailed Product Description
LED Type: SMD 3528 Pixel Configuration: 1R1G1B
Pixel Pitch: 6mm Product Name: Full Color Led Sign/indoor Led Display
Protection Ratings: IP65 Tube Chip Color: Full Color
High Light:

advertising led screens

,

indoor led display screen

Quick Detail:



P6 indoor led screens

1. Relatively low cost

2. Stable capability

3. Green product, energy saving 35%

4. Satisfactory after-sales



High Resolution Indoor Advertising LED Display P6mm 1R1G1B Energy Saving



Description:



1. Convenient and fast installation

We adapted Plug and play designing for this series, the power and signal connector is quite easy and fast

for in&out operation; and the signal connection can be in horizontal and vertical ways, it satisfied the rental

application in any cases.

2.  Super wide viewing angle (140 Degree)

The SMT technology and one line chip encapsulation optimized the viewing performance even at wide

viewing angle up to 120-140 degree, the gorgeous color uniform will satisfy the nitpicker's eyes.

3. Easy maintenance

All electrical parts was connected by a driving board inside the aluminum panel, it helps to decide which

part faults when problem comes out and can be replaced quickly.

4. High refresh rates and color contrast

In consider of the full range rental application even for the high end TV shows or Talks, we improved the

base material supplying with all pure black color ones, it enhances the white/black color contrast greatly,

further and more, we raise the refresh rates up to 4000Hz, you'll not worry about the scanning lines be

watched by your living camera.



Applications:



Commercial advertising, mobile media, night club, entertainment events, business establishments, such as

banks, stock exchange centers, bus station, schools, telecommunications, customs, stadiums, studio,

shopping malls, railways, airports, harbors, etc;



Specifications:



1. Indoor LED Display Module

Dimensions (w x h)

192mmx96mm

Resolution (w x h)

32 x 16

Pixel pitch

6mm

Pixel Density

27777/㎡

Pixel Configration

1R1G1B 3 IN 1

SMD 3528



Full Color Indoor Advertising LED Display 0

2. Indoor LED Display Cabinet

Dimensions(w x h x d)(mm)

576x576x135

Module Quantity

18

Physical Resolution (w x h)

96 x 96

Physical Pixels (total)

9216

Weight/Panel (kgs)

30

Material

Cold rolled steel

Average Power/sqm (watts)

300

Max Power/sqm(watts)

1000

Full Color Indoor Advertising LED Display 1



3. Methods for Quality Assurance

a. Aging

1. 100% fully test

2. Condition: 72 hours with 256 grey level

Full Color Indoor Advertising LED Display 2

b. Vibration Testing

Condition: 3-5 mins up and down in 5mm range

Full Color Indoor Advertising LED Display 3



4. Indoor LED Display Technical Parameter

Model No.

NS-IR-DS-P6

Pixel Pitch

6mm

Module Size

192*96mm

Module Resolution(pixels)

32*16

Pael Size

960mm×768mm

Panel Resolution(pixels)

160×128

Pixel Configuration(RGB)

1R1G1B

Pixel Density(pixels/m2)

27777

Brightness(cdm2)

2000

Best Viewing Distance(m)

6-100

Max.Power Consumption(W/m2)

1350

Waterproof Level

IP65

Vavelength

R 620-625 G 520-525 B 470-475

LED SPEC

3528

Viewing Angle

140°(H)/60°(V)

Operating Tempreture

–20~50°C

Video Frame Rate(Hz)

≥60HZ

Display Refresh Rate(Hz)

≥300HZ

Grey Level(colors)

16.7million

MTBF

≥50000 hours

Lifespan

≥100000Hours

Working Voltage

220V±15% OR 110V±15%

Drive Mode

Constant 1/8

Graphics Card

DVI Graphics card

Video Signal

RF, S-Video, RGB, RGBHV, YUV, YC, etc.

Control System

LINSN

Software

LED studio 10.0

Installation

Wall mount, hung and stand structure



5. Factory Equipment

Full Color Indoor Advertising LED Display 4



6. Package

Flight case and Fumigation-Free wooden case

Full Color Indoor Advertising LED Display 5



7. Control System Connection

Full Color Indoor Advertising LED Display 6



8. Competitive Advantage:

1.  2 years’ warranty with free repair service

2.  24/7 Hours online Remote Support

3.  Solution and PCB design

4.  Free factory training

5.  Onsite installation instruction and regular inspection
