HD High Brightness Ce Video Led Screens , 4mm Led Advertising Screen
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Cabinet Dimension: | 800*640mm | Module Size: | 160*160mm |
|---|---|---|---|
| Material: | Aluminum | LED Tube Chip: | Full Color |
| LED Configuration: | SMD 3 IN 1 | Usage: | Indoor Fixed |
| Viewing Distance: | 4m | Warranty: | 2 Years |
| High Light: | led advertising displays,led video wall display |
||
HD High Brightness Ce Video Led Screens , 4mm Led Advertising Screen
◆Advantages
1. High definition with 5mm pixel pitch and stability performance
2. Small cabinet size: 480*480mm and light weight panel which can be used in rental events
3. Faorable cost performance
Cabinet Parameter
| Cabinet Size | 800*640mm |
| Cabinet Material | Aluminum |
| Cabinet Weight | 15kg |
| Cabinet Resolution | 160*128dots |
| Cabinet Protection | Indoor use |
Module Parameter
| Pixel Pitch | 5mm |
| Pixel Configuration | 1R1G1B |
| LED type | SMD3528 |
| Module size | 160*160mm |
| Module resolution | 32*32dots |
Screen Parameter
| Pixel Pitch | 5mm |
| Driving Mode | Constant 1/16 |
| Refresh Rate | >1000Hz |
| Brightness | >1000cd/m2 |
| Power Consumption | Avg:150W/Panel |
| Grayscale | 65536level |
| Viewing Angle(H/V) | 140º/140º |
| Life span | 100,000 hours at 50% brightness |
| IP Rating | Indoor use |
| Warranty | 2 years |
Features
◆Aluminum structure,good heat dissipation with heat emission hole and high hardness
◆Small Cabinet size and light weight which make it portable and easy to install
◆High Definition with 40000 dots/㎡, good color uniformity
◆With two location poles on each panel which support hoisting and rental events
Product Review
◆Application
Indoor TV Station, Meeting Room, Teaching Hall, Indoor Theatre,Chain Store etc.
◆ Service
▪ Free Trainning: Installation, adjustment and operation
▪ After-sales Technical Support: online analysis about product default ,operation demonstration
▪ Free parts repairation and replcing during the warranty
▪ Supervise installation on construction site (Optional)
