P3.91 P4.81 P5.682 P6.25 smd led screen high resolution 4 layers PCB

Large Image : P3.91 P4.81 P5.682 P6.25 smd led screen high resolution 4 layers PCB Get Best Price

Product Details:

Place of Origin:	China
Brand Name:	OEM/ODM
Certification:	CE,ROHS
Model Number:	ES3

Payment & Shipping Terms:

Minimum Order Quantity:	1 sqm
Price:	Based on quanlity
Packaging Details:	Flight case, wooden case
Delivery Time:	20-25 days
Payment Terms:	T/T, L/C, Western Union
Supply Ability:	1000 sqm per month

Contact Now

Detailed Product Description

LED:	2020 Black	LED Chip:	Epistar
IC:	MBI5124	Driving Mode:	1/16
Refresh Rate:	≥2880Hz	Brightness:	≥1500cd/㎡
PCB:	4 Layers	LOGO:	Silk Print On Cabinet For Free
Cabinet Material:	Die Casting Alu	Module Size:	250x250mm
Cabinet Size:	500x500mm	Cabinet NW:	8KG
High Light:	outdoor rental led display , outdoor full color led display

P3.91 P4.81 P5.682 P6.25 smd led screen high resolution 4 layers PCB

With unique and market-leading seamless technology, Newstar 3.91mm LED panel effective control the video screen face precision down to 0.05mm. Your image & video will look more smooth, fluent and harmonious.

Not only 3.91mm, but also 4.81mm, 5.682mm and 6.25mm available. Meanwhile, Newstar have developed the front service version, maintenance will be 90% faster than back service, as no need to remove screws.

The specification

Pixel pitch	3.91mm	4.81mm	5.682mm	6.25mm
LED configuration	2020 black	2020 black	3528	3528
LED chip	Epistar	Epistar	Epistar	Epistar
LED package	Kinglight	Kinglight	Kinglight	Kinglight
Module size	250x250mm	250x250mm	250x250mm	250x250mm
Cabinet size	500x500mm	500x500mm	500x500mm	500x500mm
Cabinet NW	8KG	8KG	8KG	8KG
Cabinet material	Die cast Alu	Die cast Alu	Die cast Alu	Die cast Alu
Driving mode	1/16	1/13	1/11	1/10
Driving IC	MBI5124	MBI5124	MBI5124	MBI5124
Refresh rate	≥2880 Hz	≥2880 Hz	≥2880 Hz	≥2880 Hz
Brightness	≥1500 cd/㎡	≥1500 cd/㎡	≥1500 cd/㎡	≥1500 cd/㎡
PCB	4 layers	4 layers	4 layers	4 layers
Grey level	16.7 million	16.7 million	16.7 million	16.7 million
Life span	100,000 hrs	100,000 hrs	100,000 hrs	100,000 hrs
