P6 Video Indoor LED Screens , 1R1G1B 3 IN 1 LED Display Boards

Large Image : P6 Video Indoor LED Screens , 1R1G1B 3 IN 1 LED Display Boards Get Best Price

Product Details:

Place of Origin:	Shenzhen, China
Brand Name:	Newstar-LED
Certification:	CE, RoHS, UL, FCC, ISO
Model Number:	NS-IR-DS-P6

Payment & Shipping Terms:

Minimum Order Quantity:	1 pc/ 1 sqm.
Price:	US $1,000-2,000 /sqm.
Packaging Details:	Flight case /Fumigation-Free wooden case
Delivery Time:	8-25days after received the payment
Payment Terms:	T/T
Supply Ability:	2000 Square Meter/Month

Contact Now

Detailed Product Description

Product Name:	Led Display Panels/large Led Display	Pixel Pitch:	6mm
Pixel Configuration:	1R1G1B 3 IN 1	Tube Chip Color:	Full Color
Protection Ratings:	IP65	LED Type:	SMD 3528
High Light:	Rental Led Screen , RGB LED Display

Quick Detail:

1. Color and brightness uniform

2. Front maintenance

3. Excellent contrast

4. Nature vivid colors

5. High definition

6. Waterproof Level: IP65

P6 Video Indoor LED Screens , 1R1G1B 3 IN 1 LED Display Boards

Description:

1. Safety.

Using the low voltage DC so that no matter the elderly and children can safely operate without potential

safety hazard.

2. Softness.

Using PCB as the substrate and can apply to various advertising model requirements.

3. Long lifespan.

The normal operating time is 100000 hours. If worked all the day long, it would work

for at least 10 years.

4. Energy conservation and environmental protection.

Using the environmental materials and low power (0.04W-0.08W) so that cannot result in waste and

pollution.

5. Easily installation.

Using attaching clamp, wire casing, iron wire, iron net and can install on all kinds of undertake surface. It

can also be installed by the double-sided adhesive because of the light weight.

6. Pure color.

Using the high bright SMT and the color is pure, downy and no glare

Applications:

Commercial advertising, mobile media, night club, entertainment events, business establishments, such as

banks, stock exchange centers, bus station, schools, telecommunications, customs, stadiums, studio,

shopping malls, railways, airports, harbors, etc;

Specifications:

1. Indoor LED Display Technical Parameter

Model No.	NS-IR-DS-P6
Pixel Pitch	6mm
Module Size	192*96mm
Module Resolution(pixels)	32*16
Pael Size	960mm×768mm
Panel Resolution(pixels)	160×128
Pixel Configuration(RGB)	1R1G1B
Pixel Density(pixels/m2)	27777
Brightness(cdm2)	2000
Best Viewing Distance(m)	6-100
Max.Power Consumption(W/m2)	1350
Waterproof Level	IP31
wavelength	R 620-625 G 520-525 B 470-475
LED SPEC	3528
Viewing Angle	140°(H)/60°(V)
Operating Temperature	–20~50°C
Video Frame Rate(Hz)	≥60HZ
Display Refresh Rate(Hz)	≥300HZ
Grey Level(colors)	16.7million
MTBF	≥50000 hours
Lifespan	≥100000Hours
Working Voltage	220V±15% OR 110V±15%
Drive Mode	Constant 1/8
Graphics Card	DVI Graphics card
Video Signal	RF, S-Video, RGB, RGBHV, YUV, YC, etc.
Control System	LINSN
Software	LED studio 10.0
Installation	Wall mount, hung and stand structure

2. Indoor LED Display Module

Dimensions (w x h)	192mmx96mm	Resolution (w x h)	32 x 16
Pixel pitch	6mm	Pixel Density	27777/㎡
Pixel Configration	1R1G1B 3 IN 1	SMD 3528

3. Indoor LED Display Cabinet

Dimensions(w x h x d)(mm)	576x576x135	Module Quantity	18
Physical Resolution (w x h)	96 x 96	Physical Pixels (total)	9216
Weight/Panel (kgs)	30	Material	Cold rolled steel
Average Power/sqm (watts)	300	Max Power/sqm(watts)	1000

4. Methods for Quality Assurance

a. Aging

1. 100% fully test

2. Condition: 72 hours with 256 grey level

b. Vibration Testing

Condition: 3-5 mins up and down in 5mm range

5. Factory Equipment

Wave Soldering Conveyor, PC Console, Wave Soldering Machine,
Automatic Glue- pouring Machine, Solder Paste Printing Machine,
Reflow Soldering Machine, Automatic Solder Paste Printing Machine,
Withstand Voltage Tester, Ground Resistance Tester,
Medium-speed Automatic SMT Machine, Super Mute Terminal Machine,
Automatic Wire Stripping Machine, Automatic Optical Inspection (AOI) Equipement.

6. Package

Flight case and Fumigation-Free wooden case

7. Control System Connection

8. Competitive Advantage:

1. 2 years’ warranty with free repair service

2. 24/7 Hours online remote support

3. Solution and PCB design

4. Free factory training

5. Onsite installation instruction and regular inspection
