P3 Commercial Rental Led Display Advertising , Largest High Definition Video Screen

Large Image : P3 Commercial Rental Led Display Advertising , Largest High Definition Video Screen Get Best Price

Product Details:

Place of Origin:	Shenzhen, China
Brand Name:	Newstar-LED
Certification:	CE, RoHS, UL, FCC, ISO
Model Number:	NS-IR-DS-P3

Payment & Shipping Terms:

Minimum Order Quantity:	1 pc/ 1 sqm.
Price:	US $2,000-3,000 /sqm.
Packaging Details:	Flight case /Fumigation-Free wooden case
Delivery Time:	8-25days after received the payment
Payment Terms:	T/T
Supply Ability:	2000 Square Meter/Month

Contact Now

Detailed Product Description

LED Type:	SMD2020	Pixel Configuration:	1R1G1B
Pixel Pitch:	3mm	Product Name:	Led Display Boards/led Display Signs
Tube Chip Color:	Full Color	Use:	Indoor
High Light:	outdoor full color led display , outdoor led video display

P3 Commercial Rental Led Display Advertising , Largest High Definition Video Screen

Quick Detail:

Chanel LED screen supplier

1. CE RoHS ISO9001 certificate

2. 24 months warranty and Lifelong free tech-support

3. Excellent contrast ratio, high resolution/high definition

4. Perect uniformity and no mosaic

5. Light weight and easy to install

6. Available models:P3, P4, P5, P6 P7.62, P8, P10ect.

HD P3 Commercial Stage Rental Led Display For Advertising , 1R1G1B , 111111 dots/㎡

Description:

1. High Contrast and Frequency

4000:1 and 5000HZ, which is a very high level to ensure a vivid image

2. First-class LED chip

Supplied by Silan & other high strictly selected LED chip to ensure the long life time and high brightness of

our LED screen system.

3. Clear vivid image quality

Even in direct , full-on sunlight to ensure you attracts more audience to get short ROI of your LED screen's

investment.

4.Easy Installation & Using

Easy & simple installation interface and user friendly software to ensure the user friendly interface of the

LED screen system.

5. Convenient Servicing

Front or rear cabinet access make the maintains work very convenient and low cost to help you

concentrate more time and energy on your main marketing promotion business.

Applications:

Commercial advertising, mobile media, night club, entertainment events, business establishments, such as

banks, stock exchange centers, bus station, schools, telecommunications, customs, stadiums, studio,

shopping malls, railways, airports, harbors, etc;

Specifications:

1. Indoor LED Display Technical Parameter

Model No.	NS-IR-DS-P3
Pixel Pitch	3mm
Pael Size	480mm×480mm
Panel Resolution(pixels)	128×128
Pixel Configuration(RGB)	1R1G1B
Pixel Density(pixels/m2)	111111
Brightness(cdm2)	2000
Best Viewing Distance(m)	3-100
Max.Power Consumption(W/m2)	1350
Waterproof Level	IP31
Vavelength	R 620-625 G 520-525 B 470-475
LED SPEC	2020
Viewing Angle	140°(H)/60°(V)
Operating Tempreture	–20~50°C
Video Frame Rate(Hz)	≥60HZ
Display Refresh Rate(Hz)	≥300HZ
Grey Level(colors)	16.7million
MTBF	≥50000 hours
Lifespan	≥100000Hours
Working Voltage	220V±15% OR 110V±15%
Drive Mode	Constant 1/16
Graphics Card	DVI Graphics card
Video Signal	RF, S-Video, RGB, RGBHV, YUV, YC, etc.
Control System	LINSN
Software	LED studio 10.0
Installation	Wall mount, hung and stand structure
Out of Control Rate	0.01 %

2. Indoor LED Display Module

Module Size (W*H)	192mm*96mm	Pixel Configuration	1R1G1B
Pixel Pitch	3mm	Resolution (W*H)	64 dots*32 dots
Pixel Density	111111 dots/㎡	LED Type	SMD2020

3. Indoor LED Display Cabinet

Cabinet Size (W*H)	384mm*384mm	Module Qty	8 pcs
Cabinet Resolution (W*H)	128 dots*128 dots	Cabinet Pixel	16384
Weight	50 kg/ Cabinet	Area	0.6144㎡
Average Power Consumption	600w/㎡	Max Consumption	3000 W/m2

4. Methods for Quality Assurance

a. Aging

1. 100% fully test

2. Condition: 72 hours with 256 grey level

b. Vibration Testing

Condition: 3-5 mins up and down in 5mm range

5. Factory Equipment

Wave Soldering Conveyor, PC Console, Wave Soldering Machine,
Automatic Glue- pouring Machine, Solder Paste Printing Machine,
Reflow Soldering Machine, Automatic Solder Paste Printing Machine,
Withstand Voltage Tester, Ground Resistance Tester,
Medium-speed Automatic SMT Machine, Super Mute Terminal Machine,
Automatic Wire Stripping Machine, Automatic Optical Inspection (AOI) Equipement.

6. Package

Flight case and Fumigation-Free wooden case

7. Control System Connection

8. Competitive Advantage:

1. Good quality

2. Good price

3. Good 24hours service

4. Promote delivery

5. Energy-saving

6. Small order accepted
