Product Details:

Payment & Shipping Terms:

Minimum Order Quantity:	1 squre meter
Price:	negotiation
Packaging Details:	wooden case
Delivery Time:	20 working days
Payment Terms:	T/T, Western Union, MoneyGram, L/C
Supply Ability:	10000sqm/month

Contact Now

Detailed Product Description

Panel Material:	Die Casting Aluminum	Pixel Pitch:	3mm
LED Type:	SMD 2020	Module Size:	192 X 192mm
Cabinet Size:	576×576x83mm	Brightness:	≥1500 Nits
High Light:	advertising led screens , indoor led display screen

P3 Indoor front service fixed High Resolution Full Color Small Pixel Pitch LED Advertising Display

Parameter	Value	Unit
Pixel pitch	3	mm
Pixel configuration	R,G,B 3in1
SMD type	2020	—
Pixels per sq.m.	111,111	dot
Module Size	192 x 192	mm
Module Resolution	64 x 64	dot
Cabinet size (W×H×D)	576×576x83	mm
Cabinet Resolution	192 x 192	dot
Pixels per cabinet	36,864	dot
Cabinet area	0.3318	sq.m.
Cabinet material	Die Casting Aluminum	—
Cabinet weight	10	kg
Brightness	≥1500	nits
Viewing angle-H	140 (+70/-70)	deg.
Viewing angle-V	140 (+70/-70)	deg.
Ingress protection	indoor use	—
Minimum viewing distance	3	m
Gray scale	65536	level
Brightness control	256	level
Refresh frequency	>3000	Hz
Driving mode	1/16scan	—
Input voltage (AC)	100 ～ 240	V
Input power frequency	50 or 60	Hz
Power consumption per sq.m. (max/avg)	900/300	W
Blind spot rate	＜1/10000	—
Lifetime at 50% brightness	100000	Hour
Operating temperature	–25～﹢40	℃
Operating humidity	10％～ 90％	—
Signal input format (with video processor)	AV, S-Video, VGA, DVI, YPbPr, HDMI, SDI	—
