P5mm Indoor Full Color LED Display High Definition Led Display Panels
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Pixel Pitch: | 5 Mm | LED Type: | SMD3528 [black] |
|---|---|---|---|
| Certification: | CE,ETL,FCC,CCC,ROHS | Pixel Density: | 40000 Pixels/SQM |
| Brightness: | 1300cd/SQM | Refresh Rate: | 1400HZ |
| High Light: | advertising led screens,indoor led display screen |
||
P5mm Indoor Full Color LED Display High Definition Led Display Panels
Features
◆Aluminum structure,good heat dissipation with heat emission hole and high hardness
◆Small Cabinet size and light weight which make it portableand easy to install
◆High Definition with 40000 dots/㎡, good color uniformity
◆With two location poles on each panel which support hoisting and rental events
Availble Model:
1. Indoor P4 fixed led display 2. Indoor P6 fixed led display
|
Pixel Pitch |
5 mm |
|
Pixel Density |
40000 pixels/SQM |
|
LED Type |
SMD3528 [black] |
| Brightness |
1300cd/SQM |
|
Refresh Rate |
1400HZ |
|
Color Depth |
16 Bit |
|
Viewing Angle |
H:140°, V:140° |
|
Module Size |
240mm*240mm |
|
Cabinet Size |
480*480mm |
|
Cabinet Weight |
8.5Kg |
|
Material |
Aluminum |
|
Driving Method |
1/12 |
|
Power Consumption (Avg./Max.) |
260W/SQM &400W/SQM |
|
Control System |
LINSN & NOVSTAR & DEBSTAR |
|
IP Rating |
Front31 |
|
Temperature-Operating |
-20℃~40℃ |
|
Voltage Input |
110 Vac ~ 240Vac (50~60HZ) |
|
Optimal Viewing Distance |
5 m~40 m |
|
Operation System |
Windows 98/me/NT/Wins7 |
|
Certification |
CE,ETL,FCC,CCC,ROHS |
Refference:
[ Mrled: P5 Indoor Fixed LED Display, P5 Indoor Fixed LED Display |Dicolor: P5 indoor Fixed LED Display, P5 Indoor Fixed LED Screen | P5 indoor Fixed LED Display, P5 indondoor Fixed LED Display, P5 indoor Fixed LED Display ]y ] ]
What is the Advantages of NewstarP5 Indoor FixedLED Display?
◆Advantages
1. High definition with 5mm pixel pitch and stability performance
2. Small cabinet size: 480*480mm and light weight panel which can be used in rental events
3. Faorable cost performance
Application:Indoor TV Station, Meeting Room, Teaching Hall, Indoor Theatre
◆ Control System ofP5 Indoor Fixed led display
[System Confiburation Hardware]
[System Layout Sketch]
◆Packing and ShipmentofP5 Indoor Fixed led display
1.Packing Instructuction
(1) Packing case; Standard Flight case
(2) Packaged form: 6 or 8 panels in one case
2.Shipment Instruction
(1) Usually Ocean shipment and Air-transportation are widely choen as foreign transportation
(2) Forwarder appointment: can be customized
◆ Trade terms and notes aboutP5 Indoor Fixed led display
▪ FOB Price: 1000~1300 USD/㎡
▪ Payment Terms: T/T, L/C, West Union,Paypal
▪ Loading Port: Shenzhen
▪ Delivery: 20 working days
▪ Minimum Order: 5 SQM
▪ 2 Years’ Warranty
◆ Service
▪ Free Trainning: Installation, adjustment and operation
▪ After-sales Technical Support: online analysis about product default ,operation demonstration
▪ Free parts repairation and replcing during the warranty
▪ Supervise installation on construction site (Optional)
Welcome to visitShenzhen Newstar Optoelectronics Co.,Ltdbefore your choice!
