Waterproof IP65 P20 Stadium Perimeter LED Display Outdoor Rental led screen

Large Image : Waterproof IP65 P20 Stadium Perimeter LED Display Outdoor Rental led screen Get Best Price

Product Details:

Place of Origin:	Shenzhen, China
Brand Name:	Newstar-LED
Certification:	CE, RoHS, UL, FCC, ISO
Model Number:	NS-OR-DD-P20

Payment & Shipping Terms:

Minimum Order Quantity:	1 pc/ 1 sqm.
Price:	US $1,000-2,000 /sqm.
Packaging Details:	Flight case /Fumigation-Free wooden case
Delivery Time:	8-25days after received the payment
Payment Terms:	T/T
Supply Ability:	2000 Square Meter/Month

Contact Now

Detailed Product Description

High Light:

stadium led display

perimeter led screen

Waterproof IP65 P20 Curved LED Display , Flexible aluminum curtain led screen

Quick Detail:

1. 28°support adjustable

2. Waterproof and 2 years warranty

3. High Brightness more than 8000cd/sqm

4. Long lifespan up to 100,000 hours

5. Soft mark used

6. Support any format of video, RF, S-Video, RGB, RGBHV, YUV, YC, COMPOSITION

Description:

1. High Brightness

More than 8000nits and it can be sawn from long distance.

2. Soft Mask

Soft mask design delivers good protection to the players and also decreases damage to LEDs.

3. Adjustable support and quick rigging system

Flexible support design makes LED panel lean by multi angles to cater audience’s needs and quick rigging system design makes the installation and dismantle easier and faster.

4. Cost Effective LED display

16mm not only delivers enough resolution but also decrease the cost comparing with 10mm and 12mm.
5. Waterproof and 2 Year Warranty

Water Proof IP65 and 2 year warranty. LED display can work in all-weather condition very well.

Applications:

Stadium inside and outside such as football pitch, baseball, basketball etc.

Specifications:

1. Outdoor LED Display Technical Parameter

Model No.	NS-OR-DD-P20
Pixel Pitch	20mm
Module Size	320mm ×160mm
Module Resolution(dots)	16*8
Panel Size	1280mm ×960mm
Panel Resolution(dots)	64 ×48
Pixel Configuration(RGB)	1R1G1B
Pixel Density(dots/m²)	2,500
Brightness(cd/m²)	≥ 6,500
Best Viewing Distance(m)	15-300
Avg. Power Consumption(W/m²)	800
Drive Mode	Static Constant current
Wavelength	R 620-625 G 520-525 B 470-475
Viewing Angle	110°(H)/45°(V)
Operating Temperature	–20~60°C
Video Frame Rate(Hz)	≥ 60HZ
Display Refresh Rate(Hz)	≥ 300HZ
Grey Level(colors)	16.7million
Life Span	≥100,000 hours
Working Voltage	220V±15% OR 110V±15%
Video Signal Input	RF,S-Video, RGB,RGBHV,YUV,YC,COMPOSITION
Control System	LINSN OR DB-STAR

2. Outdoor LED Display Module

Module Size (W*H)	320mm *160mm	Pixel Configuration	1R1G1B
Pixel Pitch	20mm	Resolution (W*H)	16 dots *8 dots
Pixel Density	2,500 dots/㎡	LED Type	3mm Oval Lamp

3. Outdoor LED Display Cabinet

Cabinet Size (W*H)	1280mm *960mm	Module Qty	24pcs
Cabinet Resolution (W*H)	64dots *48dots	Cabinet Pixel	3,072
Average Power Consumption	800w/㎡	Cabinet material	Aluminum

4. Methods for Quality Assurance

a. Aging

b. Vibration Testing

5. Factory Equipment

Wave Soldering Conveyor, PC Console, Wave Soldering Machine,
Automatic Glue- pouring Machine, Solder Paste Printing Machine,
Reflow Soldering Machine, Automatic Solder Paste Printing Machine,
Withstand Voltage Tester, Ground Resistance Tester,
Medium-speed Automatic SMT Machine, Super Mute Terminal Machine,
Automatic Wire Stripping Machine, Automatic Optical Inspection (AOI) Equipement.

6. Package

Flight case and Fumigation-Free wooden case

7. Control System Connection

8. Competitive Advantage:

1. 24/7 Online support service

2. Free onsite maintenance / Year

3. Solution design

4. Free online training any time

5. High quality raw material used like neutrik flight connector, MBI IC etc.
