High Resolution Indoor Full Color LED Display

large.img.alt
small.img.alt small.img.alt small.img.alt

Large Image :  High Resolution Indoor Full Color LED Display Get Best Price

Product Details:
Place of Origin: Shenzhen, China
Brand Name: Newstar-LED
Certification: CE, RoHS, UL, FCC, ISO
Model Number: CS-5
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc/ 1 sqm.
Price: US $1,000-2,000 /sqm.
Packaging Details: Flight case /Fumigation-Free wooden case
Delivery Time: 8-25days after received the payment
Payment Terms: T/T
Supply Ability: 2000 Square Meter/Month
Detailed Product Description
Luminance: 2,000cd/㎡ Pixel Configuration: 1R1G1B
Pixel Pitch: 5.21mm Product Name: Full Color Led Sign/indoor Led Display
Protection Ratings: IP31 Tube Chip Color: Full Color
High Light:

advertising led screens

,

indoor led display screen



Quick Detail:



1. Excellent contrast ratio with 4000:1 , high resolution/high definition

2. Light weight and easy to move and install

3. Best uniformity and no mosaic

4. Available models: P3.91, P4.46,P5.2, P6.25.



SMD P5.21 High Resolution Indoor LED Video Display Screen For Event , Stage





Description:



1. Ultra thin cabinet

Each panel is only 500*500mm, thickness is 75mm, weights 6.5Kg.

2. Clear vivid image quality:

High refresh rate 1800Hz, without any loss of grey level.

3. Easy Installation & Operation:

Full aluminum design with exquisite design, user friendly software for an easier operation

4. Fanless design & good heat dissipation



Applications:



Commercial advertising, mobile media, night club, entertainment events, business establishments, such as

banks, stock exchange centers, bus station, schools, telecommunications, customs, stadiums, studio,

shopping malls, railways, airports, harbors, etc;



Specifications:



1. Indoor LED Display Module

Dimensions (w x h)

250mmx250mm

Resolution (w x h)

48 x 48

Pixel pitch

5.2mm

Pixel Density

36864/㎡

Pixel Configration

1R1G1B 3 IN 1





High Resolution Indoor Full Color LED Display 0

2. Indoor LED Display Cabinet

Dimensions(w x h x d)(mm)

500x500x75

Module Quantity

4

Physical Resolution (w x h)

96 x 96

Physical Pixels (total)

9216

Weight/Panel (kgs)

7.5

Material

Aluminum

Average Power/sqm (watts)

330

Max Power/sqm(watts)

900

High Resolution Indoor Full Color LED Display 1

3. Methods for Quality Assurance

a. Aging

1. 100% fully test

2. Condition: 72 hours with 256 grey level

High Resolution Indoor Full Color LED Display 2

b. Vibration Testing

Condition: 3-5 mins up and down in 5mm range

High Resolution Indoor Full Color LED Display 3



4. Indoor LED Display Technical Parameter

Technique

SMD

Pixel structure

1R1G1B 3in1

Pixel pitch

5.21mm

Pixel density

36,864 dots/㎡

Luminance

2,000cd/㎡

Module dimension

250mm(W) * 250mm(H)

Module resolution

48 pixel(W) * 48 pixel mm(H)

Cabinet dimension

500 * 500mm

Cabinet resolution

96 * 96

Cabinet area

0.25 sq.meter

Optimal visual distance

>3m

Visual angel

140 degree (H/V)

Max power consumption

≤800w / ㎡

Average power consumption

≤350w / ㎡

Brightness adjustment

Adjust according to the environment

brightness software (0%-100%adjustable)

Gray scale

Point by point 4096 gray grade levels of

each color,16 bits γ correction available

Drive mode

1/16 dynamic scan, constant current

Frame frequency

≥60HZ

Refresh frequency

≥1000HZ

Input voltage

AC 90~260 volts

Operation temperature

﹣40℃~ +60℃

Operation humidity

10%~90%

Input signal

S-video, RF, RGB, Yuv, YC, composite…

Control system

DVI card + master control card + receiver card

MTBF

>5000 hrs

Life span (50% brightness)

100,000 hrs

Malfunction dot rate

1/10000

Ingress protection rate

IP31

Cabinet material

Aluminum alloy / iron

Application:

Rental / Permanent installation available



5. Factory Equipment

High Resolution Indoor Full Color LED Display 4



6. Package

Flight case and Fumigation-Free wooden case

High Resolution Indoor Full Color LED Display 5



7. Control System Connection

High Resolution Indoor Full Color LED Display 6



8. Competitive Advantage:

1.  2 years’ warranty with free repair service

2.  24/7 Hours online Remote Support

3.  Solution and PCB design

4.  Free factory training

5.  Onsite installation instruction and regular inspection
