Curtain SMD Outdoor Advertising LED Display

large.img.alt
small.img.alt small.img.alt small.img.alt

Large Image :  Curtain SMD Outdoor Advertising LED Display Get Best Price

Product Details:
Place of Origin: Shenzhen, China
Brand Name: Newstar-LED
Certification: CE, RoHS, UL, FCC, ISO
Model Number: WS15
Payment & Shipping Terms:
Minimum Order Quantity: 1 sqm.
Price: US $1,000-2,200 /sqm.
Packaging Details: Flight case /Fumigation-Free wooden case
Delivery Time: 20-25days after received the payment
Payment Terms: T/T
Supply Ability: 2000 Square Meter/Square Meters per Month
Detailed Product Description
Tube Chip Color: Full Color Pixel Configuration: 1R1G1B
Pixel Pitch: 15mm Product Name: Led Display Panel/outdoor Full Color Led Signs
Protection Ratings: IP65(Front Side );IP54(Back Side) Use: Outdoor
High Light:

outdoor led curtain display

,

outdoor led video display



Quick Detail:



1. Waterproof Level: IP65(Front Side), IP54 (Back Side)

2. Lightweight :< 8.5KG/panel. Ultra thin: 95mm thickness

3. High brightness: >7000cd/㎡

4. CE,CCC,RoHS,UL,ISO9001



Curtain P15 Outdoor Advertising LED Display for Stage Background 4096 dots/ ㎡





Description:



1. High brightness & Waterproof

Brightness up to 7000nits, IP65 waterproof level. It provides a perfect solution for outdoor stage use.

2. Light Weight & Pretty Thin

Made by excellent aluminum material, each panel only weights 8.5 KG which makes installation job and

delivery be much more comfortable and convenient. Pretty thin thickness 95m m not only saves delivery

space but also saves installation space.

3. Angle Adjustment

Cabinet connection angle can be adjusted by -15 degree to +15 degree. This allows you can shape arc

shapes.

4. Fast Lock System & Natural Cooling System Design

Fast lock system enables installation and dismantle to be much faster: an average worker can finish 50- 70

panels per hour. Natural cool system design results in good heat dissipation and less power consuming.



Applications:



Rental, Stage, Events, Show, Exhibition, Entertainment, Concerts



Specifications:



1. 15mm LED Curtain Module

Module Size (W*H)

500mm*62.5mm

Pixel Configuration

1R1G1B

Pixel Pitch

15.625mm

     Resolution (W*H)

32dots*4 dots

Pixel Density

4096dots/㎡

LED Type

SMD 3535



2. 15mm LED Curtain Cabinet

Cabinet Size (W*H)

500mm*500mm

Module Qty

8 pcs

  Cabinet Resolution (W*H)

32 dots*32dots

Cabinet Pixel

1024

Weight

8.5kg/ Cabinet

Area

0.25㎡

Average Power Consumption

700w/㎡

Max Consumption

1500 W/m2



3. Methods for Quality Assurance

a. Aging

1. 100% fully test

2. Condition: 72 hours with 256 grey level

Curtain SMD Outdoor Advertising LED Display 0

Curtain SMD Outdoor Advertising LED Display 1

b. Vibration Testing

Condition: 3-5 mins up and down in 5mm range

Curtain SMD Outdoor Advertising LED Display 2

4. WS15 Technical Parameter

Model No.

WS15

Pixel Pitch

15.625mm

Module Size

500mm*62.5mm

Module Resolution (W*H)

32 dots*4 dots

Pixel Density

4096 dots/ ㎡

LED Type

SMD 3535

Pixel Configuration

1R1G1B

Wavelength (R.G.B)

R:625±2nm G:525±2nm B:470±2nm

Drive Mode

Dynamic 1/4 Duty Constant Current

Cabinet Size

500×500×95mm

Cabinet Resolution

32dots×32dots

Brightness

≥7000cd/㎡

Contrast

≥4000:1

Viewing Angle

140°(Horizontal )/140°(Vertical )

Best Viewing Distance

7m-300m

Grey Scale

10bits/1024levels

Color Capability

16777216

Color Temperature

5000-9300K

Maximum Power Consumption

1500 W/m2

Average Power Consumption

700 W/m2

Working Voltage

AC 220V/110V s±15% 50-60 HZ

Frame Frequency

60-85 HZ

Refresh Frequency

240 - 1000HZ

Brightness Correction

Pixel, Module, Cabinet Correction

Operating Temperature

-40~+65℃

Operating Humidity

10-90% RH

LED Lifespan

100,000 hours

MTBF

≥50,000 hours

Computer Operation System

Win 98/ Win XP/ Win 2000

Video Signal Input

RF,S-Video, RGB,RGBHV,YUV,YC,VGA, DVI, HDMI, SDI,HD-SDI ,Composite

Video Signal Output

RF, S-Video, RGB, RGBHV, YUV, YC etc.

Graphics Card

DVI Graphics Card

Control Distance

LINSN / NOVA / DB-STAR

Software

LED studio 10.0

Waterproof Level

IP65(Front Side), IP54 (Back Side

Installation

hung and stand

Out of Control Rate

0.01 %



5. Factory Equipment

Curtain SMD Outdoor Advertising LED Display 3



6. Package

Flight case or Fumigation-Free wooden case

Curtain SMD Outdoor Advertising LED Display 4



7. Control System Connection

Curtain SMD Outdoor Advertising LED Display 5

8. Competitive Advantage:

1. 24/7 Online support service

2. Free onsite maintenance / Year

3. Solution design

4. Free online training any time

5. High quality raw material used like neutrik flight connector, MBI IC etc.
