P20 Wall Mounted Front Service LED Display Outdoor For Advertising

Large Image : P20 Wall Mounted Front Service LED Display Outdoor For Advertising Get Best Price

Product Details:

Place of Origin:	Shenzhen, China
Brand Name:	Newstar-LED
Certification:	CE, RoHS, UL, FCC, ISO
Model Number:	NS-OR-DD-P20

Payment & Shipping Terms:

Minimum Order Quantity:	1 pc/ 1 sqm.
Price:	US $600-1,000 /sqm.
Packaging Details:	Flight case /Fumigation-Free wooden case
Delivery Time:	20-25days after received the payment
Payment Terms:	T/T
Supply Ability:	2000 Square Meter/Square Meters per Month

Contact Now

Detailed Product Description

Product Name:	Led Display Panels/large Led Display	Pixel Pitch:	20mm
Pixel Configuration:	1R1G1B	Tube Chip Color:	Full Color
Use:	Outdoor	LED Type:	3mm Oval Lamp
High Light:	Rental Led Screen , RGB LED Display

Quick Detail:

1.Brightness≥5000

2. Wide viewing angle and large viewing distance video LED

3. Front service

4. Energy saving

5. CE.RoHS,CCC,ISO,UL

6. Long Lifespan > 100,000 hours

P20 Wall Mounted Front Service LED Display Outdoor For Advertising

Description:

1. Durable fresh color and High brightness

65536 grey scale and the 281 billion color and more than 1200 HZ refresh rate ensure wonderful video

color presentation

2. Energy Saving

Adopt high-brightness LED with low consumption and 90% efficiency power supply saving 20% power

energy.

3. Stability and reliability

Precise manufacturing process keeps the modules rugged and durable.

Applications:

Outdoor full color digital billboards are very popular in LED display advertising field. These type digital

billboards are widely used in outdoor plaza, outdoor building, stadium, shopping mall, cross road ,highway,

airport etc;

Specifications:

1. Outdoor LED Display Technical Parameter

Item	NS-OR-SD-P20
Physical Pitch	20mm
Physical Densi(pixels/m2) (pixels/m2)	5000
LED Arrangement	1R1G1B
Module Resolution	16×8
Module Size(mm)	320×160
Cabinet Resolution	96×48
Cabinet Size(mm)	1280×960
Module Quantity	24pcs
Cabinet Weight	70KG
Brightness(cd/m2)	≥5000
Contrast	≥2000:1
View Angle	110°/50°
Minimum View Distance	10m
Maxim Power Consumption (W/m2)	1000
Ave. Power Consumption (W/m2)	350
Operating Power Source	AC90-260V 50-60HZ
Grey Scale	10bits/1024levels
Color Capacity	1.07billion
Drive Mode	Constant Current,Dynamic 1/4Duty
Frame Frequency	60-85HZ
Refresh Rate	240-1000 HZ
Brightness Adjustment	0-100 8 levels automatic
Gamma Correction	-0.5---5.0
Correction Scale level	16 bits
Color Temperature	5000-9300K
Brightness Correction	Pixel,Module,Cabinet Correction
Protection Ratings	IP65(Front Side ),IP54(Back Side)
Control Distance	UTP CAT5E:100m;Multi-mode Fiber:500m; Single-mode Fiber:10KM
Out of Control Rate	0.01%
MTBF	5000hrs
Operating life Span	100000hrs
Operating Temperature	-40°C~+65°C
Operating Humidity	10~90%RH

2. Outdoor LED Display Module

Module Size (W*H)	320mm*160mm	Pixel Configuration	1R1G1B
Pixel Pitch	20mm	Resolution (W*H)	16 dots*8 dots
Pixel Density	2500 dots/㎡	LED Type	3mm Oval Lamp

3. Outdoor LED Display Cabinet

Cabinet Size (W*H)	1280mm*960mm	Module Qty	24 pcs
Cabinet Resolution (W*H)	64 dots*48 dots	Cabinet Pixel	3072
Weight	40 kg/ Cabinet	Area	1.228㎡
Average Power Consumption	350w/㎡	Max Consumption	1000W/m2

4. Methods for Quality Assurance

a. Vibration Testing

5. Factory Equipment

Wave Soldering Conveyor, PC Console, Wave Soldering Machine,
Automatic Glue- pouring Machine, Solder Paste Printing Machine,
Reflow Soldering Machine, Automatic Solder Paste Printing Machine,
Withstand Voltage Tester, Ground Resistance Tester,
Medium-speed Automatic SMT Machine, Super Mute Terminal Machine,
Automatic Wire Stripping Machine, Automatic Optical Inspection (AOI) Equipement.

6. Package

Flight case and Fumigation-Free wooden case

7. Control System Connection

8. Competitive Advantage:

1. Long Lifespan > 100,000 hours

2. High quality and high performance

3. Front/Rear access available

4. Reasonable price, superior service.

5. Free maintenance service
